AAA Awning Co., Inc. is a dealer of Retractable Awnings provided by Accent Awning Company. The retractable information shown below is provided by Accent Awning Company, and available on their website. Clicking on any of the links below will open a new window at www.accentawning.com.

The Elite Awning system is, without fail, the most superior awning of its kind on the market today. The Elite retractable patio awning is always built using the highest quality materials. Engineered for superior versatility, durability and elegance, the Elite retractable patio awning series can do it all. With the ability to span widths from 6 ft. up to 80 feet, and with six projections ranging from 5 feet to a maximum of 13 feet, it’s easy to see why the Elite retractable awning is the most popular awning we offer. Accent’s Elite Retractable Patio Awning is offered with a wide range of options including protective hoods, multiple hardware colors, a vertical drop valance, a convenient slope adjustment system, a heavy duty arm support, as well as numerous wireless operating choices. All of these options allow you to customize the Elite retractable patio awning to meet your shading needs. The Elite retractable patio awning, unlike a wood patio cover, extends and retracts to any position, and does so without unsightly posts that block your view. The retractable nature of the Elite allows you to control your outdoor environment with a hand crank or at the touch of a switch. Warming sun when you want it, or cooling shade when you need it, all at your finger tips. Since its introduction, almost 30 years ago, the Elite has left thousands of homeowners wondering how they ever lived without it.

Optional Features

  • Wind Sensors
  • Sun/Wind Sensors
  • Timers
  • Remote Control Systems
  • Multiple Group Controls
  • Manual Override Motor — Manually operate the awning if required.SOMFY electronic controls add both convenience and protection to your awning.
  • Variable Pitch — Quickly & easily adjust the angle of the awning.
  • Variable Valance — A vertical drop valance that rolls down at the front of your retractable awning to provide additional protection against late afternoon sun.
  • Optional Hood — Adds to the aesthetic appeal of the awning and provides additional protection for the fabric when in the retracted position.
  • Minimum Width Bypass — DSX Cross-Over Arm System. The cross-over system allows the arms to overlap each other thereby enabling small widths on projections that would otherwise not be possible. Sometimes suitable in small recesses where a large projection is required. Applies to limited sizes only.

Features & Specifications

Fabric:

  • Sunbrella brand solution dyed acrylic – 150 plus solids & stripes
  • Marine/Awning grade
  • Water Repellant Fade & Stain Resistant

Thread:

  • PTFE TEFLON thread manufactured by Coats
  • THREE TIMES more durable than bonded polyester

Hardware Finish:

  • Electro-statically applied powder coated finish then oven baked for superior durability

Hardware Colors:

  • White (RAL 9010)
  • Brown (RAL 8019)
  • Cream (RAL 1015)

Arm Construction:

  • Two-part spring loaded folding arm
  • The arm consists of a thick-walled ubular aluminum extrusion with dual cable connected to individual inner tension springs
  • Arm joints are high quality cast aluminum, tumble-polished, then powdercoated
  • Cables and springs are TEFLON coated

Arm Projections:

  • 5ft ~ 6.5ft ~ 8ft ~ 10ft ~ 11.5ft. ~ 13ft

Pitch Adjustment:

  • Arms up to 10ft. have a slope ranging from 5-85 degrees
  • Arms of 11.5 & 13 ft. have a slope ranging from 5-45 degrees

Widths:

  • 6ft to 80 ft, cut to the customer’s exact requirement

Mounting Bar:

  • 40mm x 40mm powdercoated 6063-T5 aluminum extrusion

Front Bar:

  • Custom extruded 6063-T5 aluminum powdercoated profile

Roller Tube:

  • 6063-T5 Aluminum extrusion 72mm diameter

Operation:

  • Manually – Worm gear and crank handle
  • Motorized – SOMFY tubular motors housed inside the fabric roller tube

Nuts & Bolts:

  • Aircraft quality stainless steel nuts and bolts utilized throughout construction and installation
  • Retractable Awning Comparison Chart
ELITE ELITE CASSETTE UNILUX ECONOLUX
Width Range 6′ to 80′ 6′ to 19’8″ 6′ to 18′ 8’1″, 12′ & 15’10”
Projection Ranges 5, 6.5, 8, 10, 11, 13 5, 6.5, 8, 10 5, 6.5, 8, 10 6.5, 8, 10
Hardware Color-White
Hardware Color-Cream N/A N/A N/A
Hardware Color-Brown N/A N/A N/A
Fabric available 150+ Solids & Stripes 150+ Solids & Stripes 16 Solids & Stripes 5 Stock Solids
Nuts & Bolts 316 Stainless Steel 316 Stainless Steel 316 Stainless Steel 316 Stainless Steel
Fabric Roller Tube 72 mm Aluminum 72 mm Aluminum 70/78 mm Galvanized 70/78 mm Galvanized
Mounting Support Bar Powder Coated Alum 40mm Square Bar Powder Coated Alum 40mm Square Bar Powder Coated Alum 40mm Square Bar Powder Coated Alum 40mm Square Bar
Vertical Drop Valance Optional up to 19’8″ Wide Optional up to 19’8″ Wide N/A N/A
Arm Type Double Cable
Double Spring
Double Cable
Double Spring
Double Cable
Single Spring
Double Cable
Single Spring
Front Bar Powder Coated Aluminum Powder Coated Aluminum Powder Coated Aluminum Powder Coated Aluminum
Cross Arm Option

Yes (up to 10’Proj)

N/A N/A N/A
Roof Mount Available
Aluminum Hood Optional N/A Optional Optional
Manual Operation
Motor Control Options (SOMFY) Interior Switch
Remote Transmitter
Plug-In
Interior Switch
Remote Transmitter
Plug-In
Interior Switch
Remote Transmitter
Plug-In
Interior Switch
Remote Transmitter
Plug-In
Wind, Sun & Wind, Remotes & Timers Optional Optional Optional Optional
Manual Override Optional Optional Optional N/A
Thread Type TEFLON PTFE TEFLON PTFE TEFLON PTFE TEFLON PTFE
Motor & Electronics Warranty 5 Year 5 Year 5 Year 5 Year
Fabric Warranty *10 Year *10 Year *10 Year 5 Year
Arm Warranty 20 Year 20 Year 7 Year 5 Year

*2009 Update: New Generation Sunbrella has a New Pro-Rated Limited Warranty of 10 Years
